  • Waste Water Treatment Plant Tank Sedimentation Equipment Lamella Clarifier For Removal Suitable Mining
  • Waste Water Treatment Plant Tank Sedimentation Equipment Lamella Clarifier For Removal Suitable Mining
Waste Water Treatment Plant Tank Sedimentation Equipment Lamella Clarifier For Removal Suitable MiningWaste Water Treatment Plant Tank Sedimentation Equipment Lamella Clarifier For Removal Suitable Mining

Waste Water Treatment Plant Tank Sedimentation Equipment Lamella Clarifier For Removal Suitable Mining

  • Product Item : DLC-010
  • Category: Lamella Separator
  • Certification:CE Certificate
  • Capacity:1-200 m3/h
  • Function:High TSS removal
  • Wastewater Treatment Plants
  • INQUIRY   EMAIL

Lamella Separator Description


Lamella clarifier also called inclined plate sediment tank. It is good at high efficient combined type settling tank; set many dense inclined tube packing in sediment area, to make the suspended impurity in water sediment, water rise flow along inclined tube, the separated sludge down to the tank bottom along the inclined tube by gravity, then discharge it in concentration. Such tank can improve sediment efficiency 60~70%, it can improve treatment capacity 3~5 times in the same area. It can design different flow rate inclined plate sediment device according to raw waste water test report, it need dose flocculant usually.


Available options



  • Continuous operation.
  • Due to its small volume no need to allocate large storage when emptying.
  • No drive nor mechanical parts.
  • Filling and emptying time is short.
  • Small floor area footprint.
  • Modular design for future expansions.


Lamella Gravity Settler


Lamella Separator Model


DLC-I  Gravity Lamella ,V shape mud bucket, simple structure, no energy consumption.

DLC-II Lamella with scraper,Increase the mechanical transmission mechanism, the mud discharge is better and smoother, and it matches the unit with large processing capacity.

DLC-III Super hydraulic Lamella,Reduced footprint, efficient sedimentation, detachable transportation.

lamella separator

DLC
Model
Capacities
(m3/h)
Piping Connections() Physical Dimensions(m)
Inlet(a) Effluent(b) Sludge(c) Backwash(d) L W H
DLC- 5 80 80 50 50 2.55 1.6 2.9
DLC- 10 100 100 50 50 3.35 1.82 3
DLC- 15 100 100 50 50 3.35 2.02 3
DLC- 20 100 100 50 50 3.35 2.02 3
DLC- 30 150 150 50 50 4.2 2.22 3
DLC- 40 150 150 50 50 4 2.8 3
DLC- 50 200 200 50 50 4.65 2.82 3
DLC- 60 200 200 50 50 4.7 3 3
DLC- 70 250 200 50 50 6.4 2.6 3
DLC- 80 250 200 50 50 6.8 2.82 3
DLC- 100 250 250 50 50 7.05 3.02 3


Lamella Separator Advantages


Unit is Completely Assembled
Low Installation
Conservative Design 0.2 GPM/Ft2
Completely Automatic, Gravity in Gravity Out
Reduced Floor Space
Large Compartment Flocculation Tanks with Mixer for Extra Retention Time (approximately 50-60 minutes)

Inclined Plate Separators


Lamella Separator Applications


Potable water clarification
Industrial process water
Sand filter backwash
Metal finishing
Mining
Groundwater
River pre-sedimentation


Lamella plate clarifier
