Factory Supplier Static Screen Static Sieve Screen

Static Screen Wastewater Description

Static screen water is designed to provide trouble free liquid separation. The open screen design accommodates peak hydraulic flows and the deep influent head box reduces influent turbulence while delivering an even flow over the weir crest. A pivoting flow control baffle plate is provided to enhance even flow distribution and promote faster fluid removal by directing the fluid into the screen.

This is a wedge wire bending screen, used in the physical processing unit of a static screening treatment plant. The static sieve has no driving mechanism. And it does not require energy.

Static Screen Wastewater Works

Used for Dissolved air flotation as a core product, static screen as a pretreatment before  Dissolved air flotation . These screens facilitate a consistent flow and reduce the amount
of suspended solids going to the DAF unit.

The static sieve equipment we produce is manufactured from stainless sieve bars called wedge wire slots. The chassis of the equipment is manufactured from AISI 304 stainless steel or epoxy paint protected carbon steel.
Sieve opening is projected between 500 microns and 2 mm.Inlet and outlet are manufactured with flanges, thus facilitating installation.

Static Screen Wastewater Model

Static Screen Wastewater Feature

Static Screen Wastewater Application
