High Efficiency Lamella Clarifier Machine Lamella Clarifier for Sewage Treatment Plant

  • Product Item : DLC-010
  • Category: Lamella Separator
  • Certification:CE Certificate
  • Capacity:1-200 m3/h
  • Function:High TSS removal
  • Wastewater Treatment Plants
  • INQUIRY   EMAIL

Lamella Separator Description


Lamella clarifiers are capable of managing feed water with high concentration of suspended solids. Separation results will vary depending on the feed water quality and types of contaminants. The feed water enters the lamella clarifier through the inlet channel on the top and flows to the bottom of the separator. The water is led back to the top, on its way the water flows through the lamellas, onto which the solid particles settle. Treated water flows to the top and reaches the outlet by passing a weir. The sludge slides down the lamellas and is collected in the sludge funnel. A rabble rake can be installed to prevent caking of the sludge in the conical hopper. The sludge is exported at intervals.



Available options



  • Continuous operation.
  • Due to its small volume no need to allocate large storage when emptying.
  • No drive nor mechanical parts.
  • Filling and emptying time is short.
  • Small floor area footprint.
  • Modular design for future expansions.


Lamella Gravity Settler


Lamella Separator Model


DLC-I  Gravity Lamella, V shape mud bucket, simple structure, no energy consumption.

DLC-II Lamella with scraper,Increase the mechanical transmission mechanism, the mud discharge is better and smoother, and it matches the unit with large processing capacity.

DLC-III Super hydraulic Lamella,Reduced footprint, efficient sedimentation, detachable transportation.

lamella separator

DLC
Model
Capacities
(m3/h)
Piping Connections() Physical Dimensions(m)
Inlet(a) Effluent(b) Sludge(c) Backwash(d) L W H
DLC- 5 80 80 50 50 2.55 1.6 2.9
DLC- 10 100 100 50 50 3.35 1.82 3
DLC- 15 100 100 50 50 3.35 2.02 3
DLC- 20 100 100 50 50 3.35 2.02 3
DLC- 30 150 150 50 50 4.2 2.22 3
DLC- 40 150 150 50 50 4 2.8 3
DLC- 50 200 200 50 50 4.65 2.82 3
DLC- 60 200 200 50 50 4.7 3 3
DLC- 70 250 200 50 50 6.4 2.6 3
DLC- 80 250 200 50 50 6.8 2.82 3
DLC- 100 250 250 50 50 7.05 3.02 3


Lamella Separator Advantages


Modular and compact construction
Range of capacities (2, 4 & 6 m³/hr)
Stainless steel contstruction
Layout and construction customization possible
Can be fitted with a catwalk for maintenance

Inclined Plate Separators


Lamella Separator Applications


Extremely smooth surface (mud does not stick)
High resistance to shocks (stages of loading, unloading, assembly)
Excellent hardness values, stiffness, elasticity and tensile strenght
Resistance to breakage from mechanical stress
Abrasion resistance
Excellent electrical and thermal insulating properties
Unassailable to chemical agents
No water absorption
