Gravity Settler Inclined Plate Lamella Type Separator

  • Product Item : DLC-010
  • Category: Lamella Separator
  • Certification:CE Certificate
  • Capacity:1-200 m3/h
  • Function:High TSS removal
  • Wastewater Treatment Plants
  • INQUIRY   EMAIL

Lamella Separator Description


Gravity Settler is a pre-assembled, modular, high rate inclined plate settler that uses a counter-current flow principle for effective solids removal. The inclined plate concept provides an effective settling area that is equal to the field of each plate as projected onto a horizontal surface. Using the standard 2″ plate spacing and 55°-60°, up to 10 ft² of projected area become available for each square foot of land area.


Available options

  • Continuous operation.
  • Due to its small volume no need to allocate large storage when emptying.
  • No drive nor mechanical parts.
  • Filling and emptying time is short.
  • Small floor area footprint.
  • Modular design for future expansions.


Lamella Gravity Settler


Lamella Separator Model


DLC-I  Gravity Lamella ,V shape mud bucket, simple structure, no energy consumption.

DLC-II Lamella with scraper,Increase the mechanical transmission mechanism, the mud discharge is better and smoother, and it matches the unit with large processing capacity.

DLC-III Super hydraulic Lamella,Reduced footprint, efficient sedimentation, detachable transportation.

lamella separator

DLC
Model
Capacities
(m3/h)
Piping Connections() Physical Dimensions(m)
Inlet(a) Effluent(b) Sludge(c) Backwash(d) L W H
DLC- 5 80 80 50 50 2.55 1.6 2.9
DLC- 10 100 100 50 50 3.35 1.82 3
DLC- 15 100 100 50 50 3.35 2.02 3
DLC- 20 100 100 50 50 3.35 2.02 3
DLC- 30 150 150 50 50 4.2 2.22 3
DLC- 40 150 150 50 50 4 2.8 3
DLC- 50 200 200 50 50 4.65 2.82 3
DLC- 60 200 200 50 50 4.7 3 3
DLC- 70 250 200 50 50 6.4 2.6 3
DLC- 80 250 200 50 50 6.8 2.82 3
DLC- 100 250 250 50 50 7.05 3.02 3


Lamella Separator Advantages


Unit is Completely Assembled
Low Installation
Conservative Design 0.2 GPM/Ft2
Completely Automatic, Gravity in Gravity Out
Reduced Floor Space
Large Compartment Flocculation Tanks with Mixer for Extra Retention Time (approximately 50-60 minutes)

Inclined Plate Separators


Lamella Separator Applications


Water following physical-chemical treatment.
Tailings in mining and metallurgical beneficiation.
Solutions from gold leaching processes.
Wet scrubbing effluents.
Effluent treatment in pulp and paper mills.
Filter backwash.
